Industrial Clean-Tech Battery Portfolio & Systems

China tier-1 source manufacturer delivering an integrated product matrix: from automotive-grade foil stacking LFP cells and -30°C HSL semi-solid chemistry to commercial 72V swappable battery packs and proprietary smart BMS IoT electronics.

PRODUCT DIVISION O1 . ELECTROCHEMICAL CELLS

Automotive Stacking LFP & Semi-Solid Pouch Cells

Fabricated via automated layer-by-layer foil stacking at our Huzhou New Energy Base. Eliminates radial winding curvature fatigue, delivers 20% superior heat dissipation, and achieves continuous discharge currents up to 3C (160A) across an ultra-wide -30°C to 60°C thermal window.

3.2V LFP Pouch Series

20Ah to 50Ah | 2C Continuous (40A~100A) | ≥2,000 Cycles
3.67V HSL Semi-Solid Series

45Ah & 53.5Ah | 3C Continuous (135A~160A) | -30°C Cold Start

4-Parameter Sorting QC

100% OCV, ACIR, Capacity, and K-value matched lots
Safety Certification

100% SOC nail penetration pass, UN38.3 & CE verified

EXPLORE BATTERY CELLS CATALOG

PRODUCT DIVISION 02 COMMERCIAL POWER PACKS

Heavy-Duty 72V Swappable Battery Packs

Engineered for European and American commercial electric motorcycles, instant-delivery moped fleets, urban battery-swapping cabinets, and industrial AGVs. Built inside 1.2mm powder-coated steel enclosures with separate charge/discharge ports, IPX7 structural potting, and master-slave parallel scaling up to 30 units (114.5kWh).

SPB-HSL-7253-A (Flagship)

72V 53Ah (3816Wh) Semi-Solid | 132A (2.5C) Output | 26kg
SPB-LFP-7245-A (Heavy Duty)

72V 45Ah (3240Wh) LFP | 90A (2.5C) Output | 27kg

PB-LFP-7230-A (Standard)

72V 30Ah (2160Wh) LFP | 60A (2C) Rate | 28kg
Parallel Scalability

Master-slave clustering ≤ 30 packs (up to 114.5kWh)

EXPLORE BATTERY PACKS CATALOG

PRODUCT DIVISION 03EMBEDDED ELECTRONICS

Industrial Smart BMS Hardware & Protection

ANAS independently designs and manufactures proprietary battery management systems. Using 4-layer thick-copper PCBs, 4th-generation low-resistance MOS switches, and full structural silicone potting, our BMS boards manage high-drain continuous currents from 40A to 400A under extreme road vibration.

4S – 24S Universal Compatibility

Adaptive series scaling for LFP, NCM, and LTO chemistries
40A to 400A Current Handling

4th-gen MOS upgrade with superior thermal conductivity

Multi-Channel Industrial Buses

Dual UART, CAN, RS485, RS232, and Single-Wire
Peripheral Expansion Support

Connects to LCD displays, buzzer alarms, and heating films

VIEW BMS HARDWARE ARCHITECTURE

The Four Engineering Tenets Behind Every ANAS Solution

Backed by our Huzhou manufacturing cleanrooms, Taizhou testing laboratory, and Milan European service center.

Automotive Stacking Process

We replace conventional cylindrical winding with layer-by-layer automated foil stacking across all pouch cells. This eliminates internal mechanical edge stress and ensures uniform planar heat transfer.

Zero micro-dendritic formation under vehicle road vibration
5% higher volumetric packaging density in metal casings
20% faster heat dissipation to heatsinks and liquid plates
Extreme Sub-Zero Thermal Window

Our Hybrid Solid-Liquid (HSL) semi-solid chemistry eliminates low-temperature sluggishness down to -30°C, enabling instantaneous high-current starting for electric motorcycles and cold-chain warehouse AGVs.

Full power delivery in Nordic and North American winters
100% SOC nail penetration pass with zero explosion or fire
Extended lifespan of ≥2,500 deep cycles @ 90% DOD
Automated 4-Parameter Batch Sorting

Every batch of cells dispatched undergoes automated 4-parameter classification at our Taizhou testing base, guaranteeing tight curve tolerances for seamless multi-cell pack integration.

Capacity binning tolerance within tight ±0.5Ah limits
Open Circuit Voltage (OCV) & AC internal resistance matching
K-value self-discharge screening before pack assembly

SOURCING CLARITY

Frequently Asked Questions — Product Portfolio
Sourcing

Key operational answers for procurement directors, chassis engineers, and fleet operators.

Q: Can ANAS supply both bare battery cells and turnkey assembled battery packs?

A: Yes. We operate with complete vertical flexibility. Battery pack assemblers can procure bare LFP or HSL pouch cells with custom laser-welded tabs. Alternatively, commercial vehicle OEMs and swapping station operators can source turnkey, fully potted 72V sheet metal battery packs pre-programmed with custom CAN bus protocols.

Q: What is the minimum order quantity (MOQ) and production lead time across product lines?

A: For bare cells, we support pallet sample evaluation quantities. For 72V commercial battery packs, evaluation trial orders start from 1 to 5 units. Standard containerized wholesale bulk orders require 20 to 30 working days from deposit confirmation, shipped directly from our China manufacturing base with full UN-certified dangerous goods crating.

Q: How does the master-slave parallel connection work on 72V commercial battery packs?

A: Our onboard smart BMS features autonomous address negotiation and dynamic pre-charging logic that automatically isolates inrush currents between packs of unequal SOC, allowing safe parallel clustering of up to 30 packs without external master controllers.

Q: Are complete export transport documentation and overseas warranty services provided?

A: Yes. All shipments include certified UN38.3 transport reports, MSDS declarations, CE marking, and RoHS compliance certificates. ANAS provides technical warranty support and RMA processing through our European service center in Milan, Italy.

Zhejiang Anas New Energy Technology Co., Ltd. is a global manufacturer and exporter of automotive-grade LFP pouch cells, HSL semi-solid batteries, and industrial smart battery packs.
